Product information
Performance highlights
◆ Available in e-drive: full hybrid diesel-electric and plug in version or ZERO-drive: full electric drive without combustion engine onboard
◆ Global leader in the 30 tonnes class
◆ Hydraulic gap adjustment to safely prevent clogging (NSS)
◆ Optional Independent double deck vibrating pre-screen
◆ Feed size up to 500 mm (20”)
◆ Feed opening 1.000 x 600 mm (40” x 23,5”)
◆ C.S.S min. - max. 45 - 170 mm (1 3/4” - 6 11/16")
◆ Capacity up to 280 tonnes / hour
◆ Compact and easy to transport without permit
◆ Lowest fuel consumption in the industry
◆ Best product shape possible
◆ Intake hopper suitable for wheel loader and excavator, 4 m³ (5,3 yard³)
◆ High reliable closed circuit smooth drive of jaw crusher
◆ Smart sequential auto start/stop from remote
◆ Ability to track while producing
◆ 2 speed track drive
◆ Extensive option list to configure to your application
Specifications
Transport dimensions | Working dimensions | ||
Weight | 29 t (31 sT) | ||
Length | 12,435 mm (40’10”) | 12,300 mm (40’4”) | |
Height | 3,100 mm (10’2”) | 3,700 mm (12’2”) | |
Width | 2,540 mm (8’4”) | 5,525 mm (18’2”) |
Fuel efficiency
Applications
◆ Concrete and landfill recycling
◆ Construction waste
◆ Demolition Waste
◆ Primary crushing
◆ Dolomite, sandstone, most quarry applications
◆ Gravel
◆ Coal
◆ Slag and others
Cost savings
The quality of our machines mean they earn you more by working harder for longer, while keeping operational costs to the absolute minimum.
